Model:2V40/10MT-1000-AG 230/1/50

Contact us for your tailor-made price

Space saving & quiet in operation, our range of combined pump & tank systems are fitted with variable speed controlled submersible pumps which deliver a constant water pressure at varying flow demands.

Features:

• WRAS approved insulated 1000 litre nominal capacity GRP tank fitted with high flow equilibrium inlet valve allowing for quick refill of storage
• 2 no. Duty & Stand-by WRAS approved quiet running (less than 45 dBA) submersible pumps
• Energy efficient variable speed technology
• Easy installation

Sizing Information:

• Tank capacity sized for approx. 135 litres storage per person per day.
• The 2V40/10MT-1000-AG model is designed to supply a constant discharge pressure of 3.0 bar for a property with the typical following outlets:
• 2 main bathroom comprising bath, wash hand basin & WC
• 3 En Suites comprising shower, wash hand basin & WC
• Kitchen with sink, washing machine & dishwasher.
• Calculated simultaneous water demand: 54 litres per min.

Dimensions:

• 1180mm (L) x 1180mm (W) x 1580mm (H)
• Weight: 130 kg (empty) / 1130 kg (full)
